The Adjustable Automatic Oiler allows the user to adjust the lubricant of the guide bar and saw chain for different bar lengths and cutting conditions.
Technical details
| Displacement | 4.1 in³ |
| Engine power | 5.40 bhp |
| Device weight without refuelling | 12.7 lb 1) |
| System weight without refuelling | 15.7 / 17.2 / 15.9 / 15.4 / 16.2 / 16.1 / 17.1 lb 2) |
| Power-to-weight ratio | 2.4 lb/hp |
Features
The pictures shown are sample photos. The actual appearance of the equipment features and their specific attachment to the product may differ from the pictorial representations, but will have the same functionality.
STIHL has developed a system for minimizing the vibration levels of handheld outdoor power equipment. The STIHL anti-vibration system helps reduce operator fatigue and provides a more comfortable working experience.
These spikes prevent pull-in and provide better control, making cutting easier.
The decompression valve, also referred to as 'deco' or 'deco valve', vents compression in the cylinder for easier starting. The decompression valve temporarily reduces the compression in the combustion chamber during cranking and helps reduce the effort needed to pull the starter rope. It is opened manually and closes automatically as soon as the engine fires.
The Ematic™ guide bar, when used with STIHL OILOMATIC® saw chain, will provide proper lubrication and less oil consumption than conventional methods. The system works because two ramps, strategically placed in the guide bar rail, help contain the flow of oil and direct all lubrication to the sliding faces of the bar and chain links as well as the rivets and driver holes, which in turn can reduce bar oil consumption up to 50%.
Thanks to innovative engineering and construction, the MS 400 C-M delivers an excellent power-to-weight ratio.
The MS 400 C-M professional chainsaw is designed to deliver lightweight performance and jobsite productivity.
The magnesium alloy piston is lighter in weight than equivalent-size aluminum alloy pistons.
The Master Control Lever™ is an easy to use single lever, operating the choke, starting throttle lock, and on-off switch. The operator must pull the throttle trigger before moving the Master Control Lever™ to the choke position.
The modern design of the MS 400 C-M is an aesthetic reflection of the power and innovation this saw delivers.
This time-saving technology boosts the efficiency of the engine’s filter system, doubling the time between air filter cleanings. Air drawn into the engine is first separated via centrifugal force, ejecting the heavier dirt particles before being routed to the air filter. This pre-separation means less dirt to be captured by the air filter, resulting in less frequent cleaning and maintenance.
The ElastoStart™ starter handle is an exclusive feature of STIHL. It is a starting grip with a built-in shock absorber that helps reduce the effort when pulling on the starter cord. The ElastoStart™ starter grip noticeably reduces the sudden peak forces (compression) normally felt during cranking. The forces which occur at the grip after the first compression stroke are smoothed out.
This product features M-Tronic™ (M) - a new generation of Intelligent Engine Management that eliminates the low and high speed carburetor adjustment screws, compensates for dirty air filter and changes in elevation and fuel quality for optimum engine power at all times.
STIHL chainsaws are equipped with a chain stopping system designed to reduce the risk of injury in certain kickback situations. It is called a STIHL Quickstop® chain brake. The STIHL Quickstop® chain brake is designed to stop the rotation of the chain if activated by the operator’s hand or by inertia if the saw kicks back with sufficient force. In some working positions, the STIHL Quickstop® chain brake can be activated by inertia, stopping the chain within fractions of a second.
The side-access chain tensioner makes it much more convenient for the user to adjust the saw chain with a bar wrench as opposed to the typical location of the guide bar adjustment screw.
See it in action!
Simply lift the lever and twist the caps to remove or tighten. There’s no need to use a tool to tighten or loosen.
The semi-transparency allows operators to easily check the fuel level before starting work.
The Winter/Summer Shutter allows the carburetor to operate at optimum temperature year-round and helps to prevent carburetor icing when working below 50°F (10°C).
This is the world's first powerful professional chainsaw with a lightweight magnesium piston.
Built for demanding tree care and forestry work, the STIHL MS 400 C-M delivers serious professional cutting performance without added weight. Its advanced magnesium piston provides greater displacement, power, and torque than aluminum piston-equipped counterparts, giving professionals the strength to take on tough cutting jobs in a well-balanced package. STIHL M-Tronic™ engine technology automatically adjusts to changing operating conditions, helping maintain fuel-efficient, low exhaust emission performance throughout the workday.
When the work doesn’t let up, the MS 400 C-M is designed to keep downtime to a minimum. A pre-separation system removes larger debris before it reaches the air filter, extending the time between cleanings, while the long-life HD2 air filter can be cleaned instead of replaced. With intelligent engine management, purposeful weight savings, and an air filtration system built for longer run times, the MS 400 C-M gives tree care and forestry professionals the performance they need to keep demanding work moving.
Hazard Warnings
General Power Tool
Improper use of any power tool may cause serious or fatal injury. Read, understand, and follow carefully the operating and safety instructions in your instruction manual before using such products. STIHL products sold through U.S. STIHL Dealers are for distribution in the United States only. Improper use of any power tool may cause serious or fatal injury. Read, understand, and follow carefully the operating and safety instructions in your instruction manual before using such products. STIHL products sold through U.S. STIHL Dealers are for distribution in the United States only.
Proposition 65 - EnglishThis product contains chemicals known to the State of California to cause cancer and reproductive harm. www.P65Warnings.ca.gov
E-10 StatementNote: STIHL recommends use of fuel with no more than 10% Ethanol content. Using fuel with greater than 10% Ethanol content may cause damage to your equipment and may void your STIHL warranty.
