Technical details

Rated voltage36 V
Power consumption1.50 kW
Power1.20 kW 1)
Cordless power systemAK
Recommended batteryAK 30 S

Features

The pictures shown are sample photos. The actual appearance of the equipment features and their specific attachment to the product may differ from the pictorial representations, but will have the same functionality.

The advanced brushless motor virtually eliminates maintenance while supplying the power and performance you expect from STIHL.
Brushless Motor
The Ematic™ guide bar, when used with STIHL OILOMATIC® saw chain, will provide proper lubrication and less oil consumption than conventional methods. The system works because two ramps, strategically placed in the guide bar rail, help contain the flow of oil and direct all lubrication to the sliding faces of the bar and chain links as well as the rivets and driver holes, which in turn can reduce bar oil consumption up to 50%.
Ematic™ Lubrication System
This product is lightweight for easy portability, great maneuverability, and extended use.
Lightweight Portability
The Quick Chain Adjuster (QCA) (B) allows the user to adjust the tension of the chain without the use of tools. This allows for easy chain adjustment.
Quick Chain Adjuster (QCA) (B)
Soft rubber texture is both easy to grip and makes the product comfortable to hold for extended periods.
Rubberized Soft-Touch Handle
Simply lift the lever and twist the caps to remove or tighten. There’s no need to use a tool to tighten or loosen.
Toolless Fuel and Oil Caps with Retainers
Trigger-switch lockout prevents activation of the trigger-witch until depressed.
Trigger-Switch Lockout
Weighing only 10.1 lbs. and delivering 1.20 kW of power, the MSA 80 C-B yields one of the industry’s best power-to-weight ratios.
Power-to-Weight Ratio
The MSA 80 C-B is the first battery chainsaw in the AK System to feature a 14” bar, giving homeowners a heavy-duty option for firewood cutting and yard maintenance.
14” Guide Bar
The transparent oil tank makes it easy for users to keep track of oil levels.
Transparent Oil Tank - MSA 80 CB
With the ability to adjust speed depending on the job, the variable-speed trigger allows users to optimize performance and run times.
Variable-Speed Trigger
STIHL chainsaws are equipped with a chain-stopping system designed to reduce the risk of injury in certain kickback situations. It is called a STIHL Quickstop® chain brake. The STIHL Quickstop® chain brake is designed to stop the rotation of the chain if activated by the operator’s hand or by inertia if the saw kicks back with sufficient force. In some working positions, the STIHL Quickstop® chain brake can be activated by inertia, stopping the chain within fractions of a second.
STIHL Quickstop® Chain Brake System

Hazard Warnings

Proposition 65 - English

This product contains chemicals known to the State of California to cause cancer and reproductive harm. www.P65Warnings.ca.gov

General Power Tool

Improper use of any power tool may cause serious or fatal injury. Read, understand, and follow carefully the operating and safety instructions in your instruction manual before using such products. STIHL products sold through U.S. STIHL Dealers are for distribution in the United States only. Improper use of any power tool may cause serious or fatal injury. Read, understand, and follow carefully the operating and safety instructions in your instruction manual before using such products. STIHL products sold through U.S. STIHL Dealers are for distribution in the United States only.
