Technical details

Displacement2.5 cu-in
Power2 kW
Engine power2.70 HP
Engine power2.70 bhp
CO2840 g/kWh

Features

The pictures shown are sample photos. The actual appearance of the equipment features and their specific attachment to the product may differ from the pictorial representations, but will have the same functionality.

Easily remove the cover for fast and easy filter cleaning or replacement.
Air Filter Cover
STIHL has a system for minimizing the vibration levels of handheld outdoor power equipment. The STIHL anti-vibration system helps reduce operator fatigue and provides a more comfortable working experience.
Anti-Vibration System
A lined shaft provides smooth operation and less vibration.
Fully-Lined Drive Shaft
Centrifugal clutch is designed to reduce slippage.
Heavy-Duty Steel-On-Steel Clutch
Housings are lightweight, withstand greater impact, and are corrosion-resistant.
High-Tech Polymer Housing
The IntelliCarb™ Compensating Carburetor measures the air pressure on the clean side of the air filter and adjusts the metering diaphragm in the carburetor. This keeps the RPM at a consistent level, even when the air filter begins to clog.
IntelliCarb™ Compensating Carburetor
A thumb screw allows the ergonomic loop handle to be easily adjusted to the desired position without tools.
Loop Handle
Having easy access to all of the controls on one comfortable handle makes it easy to complete tasks so the operator’s hand never has to leave the handle.
Multi-Function Control Handle
A powerful low exhaust emission engine saves users fuel and operating costs without losing the power they count on to get the job done.
Powerful Low Exhaust Emission Engine
The choke is protected to help prevent damage.
Protected Choke Lever/Knob
Large baffles reduce noise level and contain a screen designed to reduce the emission of sparks.
Protected Spark Arrestor Muffler
The spark plug is protected yet easy to change.
Protected Spark Plug
Dangling and loose wires are eliminated.
Protected or Enclosed Control Cables
By pressing the bulb, this small fuel pump delivers fuel to the carburetor, reducing the number of starting pulls needed after an extended break between uses.
Purge Pump Primer
The ElastoStart™ starter handle is a feature of STIHL. It is a starting grip with a built-in shock absorber that helps reduce the effort when pulling on the starter cord. The ElastoStart™ starter grip noticeably reduces the sudden peak forces (compression) normally felt during cranking. The forces which occur at the grip after the first compression stroke are smoothed out.
STIHL ElastoStart™
The semi-automatic choke lever enables the simplified three-step start procedure, saving users time and allowing them to start jobs faster.
Semi-Automatic Choke Lever
To get started, users simply pump the fuel primer, set the choke, and pull the starter cord. The built-in stop switch allows the user to turn off the engine with a simple press of the button. When the engine is off, the throttle lock automatically returns to the "start" setting. The tool will be ready to start again when the user is ready to get back to work.
Simplified Starting Procedure
TapAction™ allows users to adjust the line length simply by tapping the cutting head against the ground.
TapAction™ AUTOCUT® Cutting Head
This safety feature must be depressed before the trigger can be activated.
Throttle Trigger Interlock
Easily check the fuel level before starting work. If fuel is needed, the upright position makes the tank easier to fill.
Upright Translucent Fuel Tank
Thanks to better air filtration due to its greater surface area, the vertical pleated paper air filter can extend the time between servicing.
Vertical Pleated Paper Air Filter

Hazard Warnings

Proposition 65 - English

This product contains chemicals known to the State of California to cause cancer and reproductive harm. www.P65Warnings.ca.gov

General Power Tool

Improper use of any power tool may cause serious or fatal injury. Read, understand, and follow carefully the operating and safety instructions in your instruction manual before using such products. STIHL products sold through U.S. STIHL Dealers are for distribution in the United States only. Improper use of any power tool may cause serious or fatal injury. Read, understand, and follow carefully the operating and safety instructions in your instruction manual before using such products. STIHL products sold through U.S. STIHL Dealers are for distribution in the United States only.

E-10 Statement

Note: STIHL  recommends use of fuel with no more than 10% Ethanol content. Using fuel  with greater than 10% Ethanol content may cause damage to your equipment and  may void your STIHL warranty.
