Technical details

Displacement1.4 cu-in
Power1.10 kW
Engine power1.50 HP
Engine power1.50 bhp
Device weight without refuelling5.7 lb 1)

Features

The pictures shown are sample photos. The actual appearance of the equipment features and their specific attachment to the product may differ from the pictorial representations, but will have the same functionality.

The Adjustable Automatic Oiler allows the user to adjust the lubricant of the guide bar and saw chain for different bar lengths and cutting conditions.
Adjustable Automatic Oiler
STIHL has developed a system for minimizing the vibration levels of handheld outdoor power equipment. The STIHL anti-vibration system helps reduce operator fatigue and provides a more comfortable working experience.
Anti-Vibration System
The built-in carry ring makes it convenient and easy to maneuver in and out of trees.
Built-In Retractable Carry Ring
These spikes prevent pull-in and provide better control, making cutting easier.
Bumper Spikes
The lightweight and easy-to-use MS 151 T C-E minimizes fatigue, allowing users to work longer and get more done.
Ease of Use with Less Fatigue
Housings are lightweight, withstand greater impact, and are corrosion-resistant.
High-Tech Polymer Housings
The IntelliCarb™ Compensating Carburetor is designed to automatically adjust the air/fuel ratio when the air filter becomes restricted or partially clogged and maintains the engine’s correct RPM. IntelliCarb™ uses air from the clean side of the air filter to control the diaphragm and flow of fuel. As the air filter becomes dirty and less air is available for the carburetor, the IntelliCarb™ system adjusts the fuel flow to compensate for the decrease in air flow. This is in contrast to typical carburetors that utilize this air from the “dirty” side of the air box.
IntelliCarb™ Compensating Carburetor
This product is lightweight for easy portability, great maneuverability, and extended use.
Lightweight Portability - Universal
A powerful low exhaust emission engine saves users fuel and operating costs without losing the power they count on to get the job done.
Powerful Low Exhaust Emission Engine
The purge pump primer feature enables the user to prime the carburetor with fuel, enabling easier starting. The purge pump primer is designed in a way that the operator cannot flood the machine by priming the carburetor too many times. Flooding the engine is still possible if the choke is not removed after the engine turns over.
Purge Pump Primer
The STIHL Easy2Start™ system makes starting STIHL outdoor power tools almost effortless, eliminating the need for a strong pull of the starting cord. This advanced starting system is designed to make starting STIHL products easier. The specific system may vary by model, but in each case, a quick pull overcomes the engine’s compression to minimize the strength and effort required to start. Available on selected products.
STIHL Easy2Start™ (E)
The chain features specially engineered grooves designed to channel oil to critical wear areas.
STIHL OILOMATIC® Saw Chain
STIHL chainsaws are equipped with a chain stopping system designed to reduce the risk of injury in certain kickback situations. It is called a STIHL Quickstop® chain brake. The STIHL Quickstop® chain brake is designed to stop the rotation of the chain if activated by the operator’s hand or by inertia if the saw kicks back with sufficient force. In some working positions, the STIHL Quickstop® chain brake can be activated by inertia, stopping the chain within fractions of a second.
STIHL Quickstop®
The side-access chain tensioner makes it much more convenient for the user to adjust the saw chain with a bar wrench as opposed to the typical location of the guide bar adjustment screw.
Side-Access Chain Tensioner
This safety feature must be depressed before the trigger can be activated.
Throttle Trigger Interlock
The top-handle model is specially designed for in-tree professional use only!
Top Handle (T)

Hazard Warnings

Proposition 65 - English

This product contains chemicals known to the State of California to cause cancer and reproductive harm. www.P65Warnings.ca.gov

General Power Tool

Improper use of any power tool may cause serious or fatal injury. Read, understand, and follow carefully the operating and safety instructions in your instruction manual before using such products. STIHL products sold through U.S. STIHL Dealers are for distribution in the United States only. Improper use of any power tool may cause serious or fatal injury. Read, understand, and follow carefully the operating and safety instructions in your instruction manual before using such products. STIHL products sold through U.S. STIHL Dealers are for distribution in the United States only.

E-10 Statement

Note: STIHL  recommends use of fuel with no more than 10% Ethanol content. Using fuel  with greater than 10% Ethanol content may cause damage to your equipment and  may void your STIHL warranty.
